Table 4-2 DMA Channels
Controller Channel Address Function
1 0 0087 Spare
1 1 0083 Spare
1 2 0081 Diskette
1 3 0082 Spare
2 4 Cascade Cascade
2 5 008B Spare
2 6 0089 Spare
2 7 008A Spare
Table 4-3 IRQ Interrupt Levels
Priority Interrupt
Number
Interrupt Source
1 SMI Power management unit
2 NMI Parity Error Detected,,I/O Channel Error
3 IRQ0 Interval Timer,,Counter 0 Output
4 IRQ1 Keyboard
IRQ 2 Interrupt from controller 2 (cascade)
5 IRQ8 Real Time Clock
6 IRQ 9 Cascaded to INT 0AH (IRQ 2)
7 IRQ10 Reserved
8IRQ
11,Reserved
9
IRQ 12,PS/2 Mouse
10 IRQ13 INT from Coprocessor
11 IRQ14 Hard Disk Controller
12 IRQ15 Reserved
13 IRQ3 Serial Comm
Port 2
14 IRQ4 Serial Comm Port 1
15 IRQ5 Reserved
16 IRQ6 Diskette Controller
17 IRQ7 Parallel Port
4-4
Theory
