Table B-5 LCD Signal Connector (J12) Pin Assignments

Pin Name Pin

Pin Name

1N.C. 21PLD16

2 LCD+5 22 PLC17

3N.C. 23PLD18

4PMOD 24PLD19

5GND 25GND

6PSLD3 26PLFS

7PSLD2 27PLP

8 PSLD1 28 PSHFCLK

9 PSLD0 29 DISPLAY

10 PSUD7 30 LCD+5

11 PSUD6 31 GND

12 PSUD5 32 LCDVEE

13 PSUD4 33 PUD0

14 GND 34 PUD1

15 GND 35 PUD2

16 N.C 36 PUD3

17 PLD23 37 PLD0

18 PLC22 38 PLD1

19 PLD21 39 PLD2

20 PLD20 40 PLD3

Connector Pinouts

B-3
