MSP430F5529 , MSP430F5528 , MSP430F5527 , MSP430F5526
MSP430F5525 , MSP430F5524 , MSP430F5522 , MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
www.ti.com SLAS590M –MARCH 2009–REVISED NOVEMBER 2015
Table 6-62. MSP430F552x Device Descriptor Table
(1)
(continued)
VALUE
SIZE
DESCRIPTION ADDRESS
(bytes)
F5529 F5528 F5527 F5526 F5525 F5524 F5522 F5521
0Ch 0Ch 0Ch 0Ch 0Ch 0Ch 0Ch 0Ch
USCI_A/B 2
90h 90h 90h 90h 90h 90h 90h 90h
04h 04h 04h 04h 04h 04h 04h 04h
USCI_A/B 2
90h 90h 90h 90h 90h 90h 90h 90h
10h 10h 10h 10h 10h 10h 10h 10h
ADC12_A 2
D1h D1h D1h D1h D1h D1h D1h D1h
1Ch 1Ch 1Ch 1Ch 1Ch 1Ch 1Ch 1Ch
COMP_B 2
A8h A8h A8h A8h A8h A8h A8h A8h
04h 04h 04h 04h 04h 04h 04h 04h
USB 2
98h 98h 98h 98h 98h 98h 98h 98h
Interrupts COMP_B 1 A8h A8h A8h A8h A8h A8h A8h A8h
TB0.CCIFG0 1 64h 64h 64h 64h 64h 64h 64h 64h
TB0.CCIFG1..6 1 65h 65h 65h 65h 65h 65h 65h 65h
WDTIFG 1 40h 40h 40h 40h 40h 40h 40h 40h
USCI_A0 1 90h 90h 90h 90h 90h 90h 90h 90h
USCI_B0 1 91h 91h 91h 91h 91h 91h 91h 91h
ADC12_A 1 D0h D0h D0h D0h D0h D0h D0h D0h
TA0.CCIFG0 1 60h 60h 60h 60h 60h 60h 60h 60h
TA0.CCIFG1..4 1 61h 61h 61h 61h 61h 61h 61h 61h
USB 1 98h 98h 98h 98h 98h 98h 98h 98h
DMA 1 46h 46h 46h 46h 46h 46h 46h 46h
TA1.CCIFG0 1 62h 62h 62h 62h 62h 62h 62h 62h
TA1.CCIFG1..2 1 63h 63h 63h 63h 63h 63h 63h 63h
P1 1 50h 50h 50h 50h 50h 50h 50h 50h
USCI_A1 1 92h 92h 92h 92h 92h 92h 92h 92h
USCI_B1 1 93h 93h 93h 93h 93h 93h 93h 93h
TA1.CCIFG0 1 66h 66h 66h 66h 66h 66h 66h 66h
TA1.CCIFG1..2 1 67h 67h 67h 67h 67h 67h 67h 67h
P2 1 51h 51h 51h 51h 51h 51h 51h 51h
RTC_A 1 68h 68h 68h 68h 68h 68h 68h 68h
delimiter 1 00h 00h 00h 00h 00h 00h 00h 00h
Table 6-63. MSP430F551x Device Descriptor Table
(1)
VALUE
SIZE
DESCRIPTION ADDRESS
(bytes)
F5519 F5517 F5515 F5514 F5513
Info Block Info length 01A00h 1 55h 55h 55h 55h 55h
CRC length 01A01h 1 19h 17h 15h 14h 13h
CRC value 01A02h 2 per unit per unit per unit per unit per unit
Device ID 01A04h 1 22h 21h 55h 55h 20h
Device ID 01A05h 1 80h 80h 15h 14h 80h
Hardware revision 01A06h 1 per unit per unit per unit per unit per unit
Firmware revision 01A07h 1 per unit per unit per unit per unit per unit
Die Record Die Record Tag 01A08h 1 08h 08h 08h 08h 08h
Die Record length 01A09h 1 0Ah 0Ah 0Ah 0Ah 0Ah
Lot/Wafer ID 01A0Ah 4 per unit per unit per unit per unit per unit
Die X position 01A0Eh 2 per unit per unit per unit per unit per unit
Die Y position 01A10h 2 per unit per unit per unit per unit per unit
Test results 01A12h 2 per unit per unit per unit per unit per unit
ADC12 Calibration ADC12 Calibration Tag 01A14h 1 05h 05h 11h 11h 05h
ADC12 Calibration length 01A15h 1 10h 10h 10h 10h 10h
ADC Gain Factor 01A16h 2 blank blank blank blank blank
(1) NA = Not applicable, blank = unused and reads FFh.
