6.9.21 Peripheral File Map
Table 6-15 lists the base address for the registers of each module. The following tables list the offsets for
all available registers in each module.
Table 6-15. Peripherals
OFFSET ADDRESS
MODULE NAME BASE ADDRESS
RANGE
Special Functions (see Table 6-16) 0100h 000h-01Fh
PMM (see Table 6-17) 0120h 000h-010h
Flash Control (see Table 6-18) 0140h 000h-00Fh
CRC16 (see Table 6-19) 0150h 000h-007h
RAM Control (see Table 6-20) 0158h 000h-001h
Watchdog (see Table 6-21) 015Ch 000h-001h
UCS (see Table 6-22) 0160h 000h-01Fh
SYS (see Table 6-23) 0180h 000h-01Fh
Shared Reference (see Table 6-24) 01B0h 000h-001h
Port Mapping Control (see Table 6-25) 01C0h 000h-002h
Port Mapping Port P4 (see Table 6-25) 01E0h 000h-007h
Port P1 and P2 (see Table 6-26) 0200h 000h-01Fh
Port P3 and P4 (see Table 6-27) 0220h 000h-00Bh
Port P5 and P6 (see Table 6-28) 0240h 000h-00Bh
Port P7 and P8 (see Table 6-29) 0260h 000h-00Bh
Port PJ (see Table 6-30) 0320h 000h-01Fh
TA0 (see Table 6-31) 0340h 000h-02Eh
TA1 (see Table 6-32) 0380h 000h-02Eh
TB0 (see Table 6-33) 03C0h 000h-02Eh
TA2 (see Table 6-34) 0400h 000h-02Eh
Real-Time Clock (RTC_A) (see Table 6-35) 04A0h 000h-01Bh
32-Bit Hardware Multiplier (see Table 6-36) 04C0h 000h-02Fh
DMA General Control (see Table 6-37) 0500h 000h-00Fh
DMA Channel 0 (see Table 6-37) 0510h 000h-00Ah
DMA Channel 1 (see Table 6-37) 0520h 000h-00Ah
DMA Channel 2 (see Table 6-37) 0530h 000h-00Ah
USCI_A0 (see Table 6-38) 05C0h 000h-01Fh
USCI_B0 (see Table 6-39) 05E0h 000h-01Fh
USCI_A1 (see Table 6-40) 0600h 000h-01Fh
USCI_B1 (see Table 6-41) 0620h 000h-01Fh
ADC12_A (see Table 6-42) 0700h 000h-03Eh
Comparator_B (see Table 6-43) 08C0h 000h-00Fh
USB Configuration (see Table 6-44) 0900h 000h-014h
USB Control (see Table 6-45) 0920h 000h-01Fh
