Table 6-33. TB0 Registers (Base Address: 03C0h)
REGISTER DESCRIPTION REGISTER OFFSET
TB0 control TB0CTL 00h
Capture/compare control 0 TB0CCTL0 02h
Capture/compare control 1 TB0CCTL1 04h
Capture/compare control 2 TB0CCTL2 06h
Capture/compare control 3 TB0CCTL3 08h
Capture/compare control 4 TB0CCTL4 0Ah
Capture/compare control 5 TB0CCTL5 0Ch
Capture/compare control 6 TB0CCTL6 0Eh
TB0 register TB0R 10h
Capture/compare register 0 TB0CCR0 12h
Capture/compare register 1 TB0CCR1 14h
Capture/compare register 2 TB0CCR2 16h
Capture/compare register 3 TB0CCR3 18h
Capture/compare register 4 TB0CCR4 1Ah
Capture/compare register 5 TB0CCR5 1Ch
Capture/compare register 6 TB0CCR6 1Eh
TB0 expansion register 0 TB0EX0 20h
TB0 interrupt vector TB0IV 2Eh
Table 6-34. TA2 Registers (Base Address: 0400h)
REGISTER DESCRIPTION REGISTER OFFSET
TA2 control TA2CTL 00h
Capture/compare control 0 TA2CCTL0 02h
Capture/compare control 1 TA2CCTL1 04h
Capture/compare control 2 TA2CCTL2 06h
TA2 counter register TA2R 10h
Capture/compare register 0 TA2CCR0 12h
Capture/compare register 1 TA2CCR1 14h
Capture/compare register 2 TA2CCR2 16h
TA2 expansion register 0 TA2EX0 20h
TA2 interrupt vector TA2IV 2Eh
