MSP430F5529
,
MSP430F5528
,
MSP430F5527
,
MSP430F5526
MSP430F5525
,
MSP430F5524
,
MSP430F5522
,
MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015
www.ti.com
Table 6-43. Comparator_B Registers (Base Address: 08C0h)
REGISTER DESCRIPTION REGISTER OFFSET
Comp_B control register 0 CBCTL0 00h
Comp_B control register 1 CBCTL1 02h
Comp_B control register 2 CBCTL2 04h
Comp_B control register 3 CBCTL3 06h
Comp_B interrupt register CBINT 0Ch
Comp_B interrupt vector word CBIV 0Eh
Table 6-44. USB Configuration Registers (Base Address: 0900h)
REGISTER DESCRIPTION REGISTER OFFSET
USB key and ID USBKEYID 00h
USB module configuration USBCNF 02h
USB PHY control USBPHYCTL 04h
USB power control USBPWRCTL 08h
USB PLL control USBPLLCTL 10h
USB PLL divider USBPLLDIV 12h
USB PLL interrupts USBPLLIR 14h
Table 6-45. USB Control Registers (Base Address: 0920h)
REGISTER DESCRIPTION REGISTER OFFSET
Input endpoint_0 configuration USBIEPCNF_0 00h
Input endpoint_0 byte count USBIEPCNT_0 01h
Output endpoint_0 configuration USBOEPCNF_0 02h
Output endpoint_0 byte count USBOEPCNT_0 03h
Input endpoint interrupt enables USBIEPIE 0Eh
Output endpoint interrupt enables USBOEPIE 0Fh
Input endpoint interrupt flags USBIEPIFG 10h
Output endpoint interrupt flags USBOEPIFG 11h
USB interrupt vector USBIV 12h
USB maintenance USBMAINT 16h
Timestamp USBTSREG 18h
USB frame number USBFN 1Ah
USB control USBCTL 1Ch
USB interrupt enables USBIE 1Dh
USB interrupt flags USBIFG 1Eh
Function address USBFUNADR 1Fh
80 Detailed Description Copyright © 2009–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: MSP430F5529 MSP430F5528 MSP430F5527 MSP430F5526 MSP430F5525 MSP430F5524
MSP430F5522 MSP430F5521 MSP430F5519 MSP430F5517 MSP430F5515 MSP430F5514 MSP430F5513
