Table 6-13. EDMA3 Channel Controller (EDMA3CC) Registers (continued)

EDMA3_0 Channel

Controller 0

BYTE ADDRESS

EDMA3_1 Channel

Controller 0

BYTE ADDRESS

ACRONYM REGISTER DESCRIPTION

Global Channel Registers

0x01C0 1000 0x01E3 1000 ER Event Register

0x01C0 1008 0x01E3 1008 ECR Event Clear Register

0x01C0 1010 0x01E3 1010 ESR Event Set Register

0x01C0 1018 0x01E3 1018 CER Chained Event Register

0x01C0 1020 0x01E3 1020 EER Event Enable Register

0x01C0 1028 0x01E3 1028 EECR Event Enable Clear Register

0x01C0 1030 0x01E3 1030 EESR Event Enable Set Register

0x01C0 1038 0x01E3 1038 SER Secondary Event Register

0x01C0 1040 0x01E3 1040 SECR Secondary Event Clear Register

0x01C0 1050 0x01E3 1050 IER Interrupt Enable Register

0x01C0 1058 0x01E3 1058 IECR Interrupt Enable Clear Register

0x01C0 1060 0x01E3 1060 IESR Interrupt Enable Set Register

0x01C0 1068 0x01E3 1068 IPR Interrupt Pending Register

0x01C0 1070 0x01E3 1070 ICR Interrupt Clear Register

0x01C0 1078 0x01E3 1078 IEVAL Interrupt Evaluate Register

0x01C0 1080 0x01E3 1080 QER QDMA Event Register

0x01C0 1084 0x01E3 1084 QEER QDMA Event Enable Register

0x01C0 1088 0x01E3 1088 QEECR QDMA Event Enable Clear Register

0x01C0 108C 0x01E3 108C QEESR QDMA Event Enable Set Register

0x01C0 1090 0x01E3 1090 QSER QDMA Secondary Event Register

0x01C0 1094 0x01E3 1094 QSECR QDMA Secondary Event Clear Register

Shadow Region 0 Channel Registers

0x01C0 2000 0x01E3 2000 ER Event Register

0x01C0 2008 0x01E3 2008 ECR Event Clear Register

0x01C0 2010 0x01E3 2010 ESR Event Set Register

0x01C0 2018 0x01E3 2018 CER Chained Event Register

0x01C0 2020 0x01E3 2020 EER Event Enable Register

0x01C0 2028 0x01E3 2028 EECR Event Enable Clear Register

0x01C0 2030 0x01E3 2030 EESR Event Enable Set Register

0x01C0 2038 0x01E3 2038 SER Secondary Event Register

0x01C0 2040 0x01E3 2040 SECR Secondary Event Clear Register

0x01C0 2050 0x01E3 2050 IER Interrupt Enable Register

0x01C0 2058 0x01E3 2058 IECR Interrupt Enable Clear Register

0x01C0 2060 0x01E3 2060 IESR Interrupt Enable Set Register

0x01C0 2068 0x01E3 2068 IPR Interrupt Pending Register

0x01C0 2070 0x01E3 2070 ICR Interrupt Clear Register

0x01C0 2078 0x01E3 2078 IEVAL Interrupt Evaluate Register

0x01C0 2080 0x01E3 2080 QER QDMA Event Register

0x01C0 2084 0x01E3 2084 QEER QDMA Event Enable Register

0x01C0 2088 0x01E3 2088 QEECR QDMA Event Enable Clear Register

0x01C0 208C 0x01E3 208C QEESR QDMA Event Enable Set Register

0x01C0 2090 0x01E3 2090 QSER QDMA Secondary Event Register

0x01C0 2094 0x01E3 2094 QSECR QDMA Secondary Event Clear Register
