104

TMS320C6748

SPRS590G –JUNE 2009–REVISED JANUARY 2017

www.ti.com

Submit Documentation Feedback

Product Folder Links: TMS320C6748

Table 6-13. EDMA3 Channel Controller (EDMA3CC) Registers (continued)

EDMA3_0 Channel

Controller 0

BYTE ADDRESS

EDMA3_1 Channel

Controller 0

BYTE ADDRESS

ACRONYM REGISTER DESCRIPTION

Shadow Region 1 Channel Registers

0x01C0 2200 0x01E3 2200 ER Event Register

0x01C0 2208 0x01E3 2208 ECR Event Clear Register

0x01C0 2210 0x01E3 2210 ESR Event Set Register

0x01C0 2218 0x01E3 2218 CER Chained Event Register

0x01C0 2220 0x01E3 2220 EER Event Enable Register

0x01C0 2228 0x01E3 2228 EECR Event Enable Clear Register

0x01C0 2230 0x01E3 2230 EESR Event Enable Set Register

0x01C0 2238 0x01E3 2238 SER Secondary Event Register

0x01C0 2240 0x01E3 2240 SECR Secondary Event Clear Register

0x01C0 2250 0x01E3 2250 IER Interrupt Enable Register

0x01C0 2258 0x01E3 2258 IECR Interrupt Enable Clear Register

0x01C0 2260 0x01E3 2260 IESR Interrupt Enable Set Register

0x01C0 2268 0x01E3 2268 IPR Interrupt Pending Register

0x01C0 2270 0x01E3 2270 ICR Interrupt Clear Register

0x01C0 2278 0x01E3 2278 IEVAL Interrupt Evaluate Register

0x01C0 2280 0x01E3 2280 QER QDMA Event Register

0x01C0 2284 0x01E3 2284 QEER QDMA Event Enable Register

0x01C0 2288 0x01E3 2288 QEECR QDMA Event Enable Clear Register

0x01C0 228C 0x01E3 228C QEESR QDMA Event Enable Set Register

0x01C0 2290 0x01E3 2290 QSER QDMA Secondary Event Register

0x01C0 2294 0x01E3 2294 QSECR QDMA Secondary Event Clear Register

0x01C0 4000 - 0x01C0 4FFF 0x01E3 4000 - 0x01E3 4FFF — Parameter RAM (PaRAM)

Table 6-14. EDMA3 Transfer Controller (EDMA3TC) Registers

EDMA3_0

Transfer

Controller 0

BYTE ADDRESS

EDMA3_0

Transfer

Controller 1

BYTE ADDRESS

EDMA3_1

Transfer

Controller 0

BYTE ADDRESS

ACRONYM REGISTER DESCRIPTION

0x01C0 8000 0x01C0 8400 0x01E3 8000 PID Peripheral Identification Register

0x01C0 8004 0x01C0 8404 0x01E3 8004 TCCFG EDMA3TC Configuration Register

0x01C0 8100 0x01C0 8500 0x01E3 8100 TCSTAT EDMA3TC Channel Status Register

0x01C0 8120 0x01C0 8520 0x01E3 8120 ERRSTAT Error Status Register

0x01C0 8124 0x01C0 8524 0x01E3 8124 ERREN Error Enable Register

0x01C0 8128 0x01C0 8528 0x01E3 8128 ERRCLR Error Clear Register

0x01C0 812C 0x01C0 852C 0x01E3 812C ERRDET Error Details Register

0x01C0 8130 0x01C0 8530 0x01E3 8130 ERRCMD Error Interrupt Command Register

0x01C0 8140 0x01C0 8540 0x01E3 8140 RDRATE Read Command Rate Register

0x01C0 8240 0x01C0 8640 0x01E3 8240 SAOPT Source Active Options Register

0x01C0 8244 0x01C0 8644 0x01E3 8244 SASRC Source Active Source Address Register

0x01C0 8248 0x01C0 8648 0x01E3 8248 SACNT Source Active Count Register

0x01C0 824C 0x01C0 864C 0x01E3 824C SADST Source Active Destination Address Register

0x01C0 8250 0x01C0 8650 0x01E3 8250 SABIDX Source Active B-Index Register

0x01C0 8254 0x01C0 8654 0x01E3 8254 SAMPPRXY Source Active Memory Protection Proxy Register

0x01C0 8258 0x01C0 8658 0x01E3 8258 SACNTRLD Source Active Count Reload Register

0x01C0 825C 0x01C0 865C 0x01E3 825C SASRCBREF Source Active Source Address B-Reference Register

0x01C0 8260 0x01C0 8660 0x01E3 8260 SADSTBREF Source Active Destination Address B-Reference Register
