139
TMS320C6748
www.ti.com SPRS590G –JUNE 2009–REVISED JANUARY 2017
Submit Documentation Feedback
Product Folder Links: TMS320C6748
Peripheral Information and Electrical SpecificationsCopyright © 2009–2017, Texas Instruments Incorporated
6.14.1 SATA Register Descriptions
Table 6-42 is a list of the SATA Controller registers.
Table 6-42. SATA Controller Registers
BYTE ADDRESS ACRONYM REGISTER DESCRIPTION
0x01E1 8000 CAP HBA Capabilities Register
0x01E1 8004 GHC Global HBA Control Register
0x01E1 8008 IS Interrupt Status Register
0x01E1 800C PI Ports Implemented Register
0x01E1 8010 VS AHCI Version Register
0x01E1 8014 CCC_CTL Command Completion Coalescing Control Register
0x01E1 8018 CCC_PORTS Command Completion Coalescing Ports Register
0x01E1 80A0 BISTAFR BIST Active FIS Register
0x01E1 80A4 BISTCR BIST Control Register
0x01E1 80A8 BISTFCTR BIST FIS Count Register
0x01E1 80AC BISTSR BIST Status Register
0x01E1 80B0 BISTDECR BIST DWORD Error Count Register
0x01E1 80E0 TIMER1MS BIST DWORD Error Count Register
0x01E1 80E8 GPARAM1R Global Parameter 1 Register
0x01E1 80EC GPARAM2R Global Parameter 2 Register
0x01E1 80F0 PPARAMR Port Parameter Register
0x01E1 80F4 TESTR Test Register
0x01E1 80F8 VERSIONR Version Register
0x01E1 80FC IDR ID Register
0x01E1 8100 P0CLB Port Command List Base Address Register
0x01E1 8108 P0FB Port FIS Base Address Register
0x01E1 8110 P0IS Port Interrupt Status Register
0x01E1 8114 P0IE Port Interrupt Enable Register
0x01E1 8118 P0CMD Port Command Register
0x01E1 8120 P0TFD Port Task File Data Register
0x01E1 8124 P0SIG Port Signature Register
0x01E1 8128 P0SSTS Port Serial ATA Status Register
0x01E1 812C P0SCTL Port Serial ATA Control Register
0x01E1 8130 P0SERR Port Serial ATA Error Register
0x01E1 8134 P0SACT Port Serial ATA Active Register
0x01E1 8138 P0CI Port Command Issue Register
0x01E1 813C P0SNTF Port Serial ATA Notification Register
0x01E1 8170 P0DMACR Port DMA Control Register
0x01E1 8178 P0PHYCR Port PHY Control Register
0x01E1 817C P0PHYSR Port PHY Status Register
