Table 3-3. C674x L1/L2 Memory Protection Registers (continued)
HEX ADDRESS RANGE REGISTER ACRONYM DESCRIPTION
(1) These addresses correspond to the L1P memory protection page attribute registers 0-15 (L1PMPPA0-L1PMPPA15) of the C674x
megamaodule. These registers are not supported for this device.
0x0184 A2E0 L2MPPA56
L2 memory protection page attribute register 56 (controls memory address
0x007C 0000 - 0x007C 7FFF)
0x0184 A2E4 L2MPPA57
L2 memory protection page attribute register 57 (controls memory address
0x007C 8000 - 0x007C FFFF)
0x0184 A2E8 L2MPPA58
L2 memory protection page attribute register 58 (controls memory address
0x007D 0000 - 0x007D 7FFF)
0x0184 A2EC L2MPPA59
L2 memory protection page attribute register 59 (controls memory address
0x007D 8000 - 0x007D FFFF)
0x0184 A2F0 L2MPPA60
L2 memory protection page attribute register 60 (controls memory address
0x007E 0000 - 0x007E 7FFF)
0x0184 A2F4 L2MPPA61
L2 memory protection page attribute register 61 (controls memory address
0x007E 8000 - 0x007E FFFF)
0x0184 A2F8 L2MPPA62
L2 memory protection page attribute register 62 (controls memory address
0x007F 0000 - 0x007F 7FFF)
0x0184 A2FC L2MPPA63
L2 memory protection page attribute register 63 (controls memory address
0x007F 8000 - 0x007F FFFF)
0x0184 A300 - 0x0184 A3FF - Reserved
0x0184 A400 L1PMPFAR L1P memory protection fault address register
0x0184 A404 L1PMPFSR L1P memory protection fault status register
0x0184 A408 L1PMPFCR L1P memory protection fault command register
0x0184 A40C - 0x0184 A4FF - Reserved
0x0184 A500 L1PMPLK0 L1P memory protection lock key bits [31:0]
0x0184 A504 L1PMPLK1 L1P memory protection lock key bits [63:32]
0x0184 A508 L1PMPLK2 L1P memory protection lock key bits [95:64]
0x0184 A50C L1PMPLK3 L1P memory protection lock key bits [127:96]
0x0184 A510 L1PMPLKCMD L1P memory protection lock key command register
0x0184 A514 L1PMPLKSTAT L1P memory protection lock key status register
0x0184 A518 - 0x0184 A5FF - Reserved
0x0184 A600 - 0x0184 A63F - Reserved
(1)
0x0184 A640 L1PMPPA16
L1P memory protection page attribute register 16 (controls memory address
0x00E0 0000 - 0x00E0 07FF)
0x0184 A644 L1PMPPA17
L1P memory protection page attribute register 17 (controls memory address
0x00E0 0800 - 0x00E0 0FFF)
0x0184 A648 L1PMPPA18
L1P memory protection page attribute register 18 (controls memory address
0x00E0 1000 - 0x00E0 17FF)
0x0184 A64C L1PMPPA19
L1P memory protection page attribute register 19 (controls memory address
0x00E0 1800 - 0x00E0 1FFF)
0x0184 A650 L1PMPPA20
L1P memory protection page attribute register 20 (controls memory address
0x00E0 2000 - 0x00E0 27FF)
0x0184 A654 L1PMPPA21
L1P memory protection page attribute register 21 (controls memory address
0x00E0 2800 - 0x00E0 2FFF)
0x0184 A658 L1PMPPA22
L1P memory protection page attribute register 22 (controls memory address
0x00E0 3000 - 0x00E0 37FF)
0x0184 A65C L1PMPPA23
L1P memory protection page attribute register 23 (controls memory address
0x00E0 3800 - 0x00E0 3FFF)
0x0184 A660 L1PMPPA24
L1P memory protection page attribute register 24 (controls memory address
0x00E0 4000 - 0x00E0 47FF)
0x0184 A664 L1PMPPA25
L1P memory protection page attribute register 25 (controls memory address
0x00E0 4800 - 0x00E0 4FFF)
0x0184 A668 L1PMPPA26
L1P memory protection page attribute register 26 (controls memory address
0x00E0 5000 - 0x00E0 57FF)
