Table 3-3. C674x L1/L2 Memory Protection Registers (continued)
HEX ADDRESS RANGE REGISTER ACRONYM DESCRIPTION
(2) These addresses correspond to the L1D memory protection page attribute registers 0-15 (L1DMPPA0-L1DMPPA15) of the C674x
megamaodule. These registers are not supported for this device.
0x0184 A66C L1PMPPA27
L1P memory protection page attribute register 27 (controls memory address
0x00E0 5800 - 0x00E0 5FFF)
0x0184 A670 L1PMPPA28
L1P memory protection page attribute register 28 (controls memory address
0x00E0 6000 - 0x00E0 67FF)
0x0184 A674 L1PMPPA29
L1P memory protection page attribute register 29 (controls memory address
0x00E0 6800 - 0x00E0 6FFF)
0x0184 A678 L1PMPPA30
L1P memory protection page attribute register 30 (controls memory address
0x00E0 7000 - 0x00E0 77FF)
0x0184 A67C L1PMPPA31
L1P memory protection page attribute register 31 (controls memory address
0x00E0 7800 - 0x00E0 7FFF)
0x0184 A67F – 0x0184 ABFF - Reserved
0x0184 AC00 L1DMPFAR L1D memory protection fault address register
0x0184 AC04 L1DMPFSR L1D memory protection fault status register
0x0184 AC08 L1DMPFCR L1D memory protection fault command register
0x0184 AC0C - 0x0184 ACFF - Reserved
0x0184 AD00 L1DMPLK0 L1D memory protection lock key bits [31:0]
0x0184 AD04 L1DMPLK1 L1D memory protection lock key bits [63:32]
0x0184 AD08 L1DMPLK2 L1D memory protection lock key bits [95:64]
0x0184 AD0C L1DMPLK3 L1D memory protection lock key bits [127:96]
0x0184 AD10 L1DMPLKCMD L1D memory protection lock key command register
0x0184 AD14 L1DMPLKSTAT L1D memory protection lock key status register
0x0184 AD18 - 0x0184 ADFF - Reserved
0x0184 AE00 - 0x0184 AE3F - Reserved
(2)
0x0184 AE40 L1DMPPA16
L1D memory protection page attribute register 16 (controls memory address
0x00F0 0000 - 0x00F0 07FF)
0x0184 AE44 L1DMPPA17
L1D memory protection page attribute register 17 (controls memory address
0x00F0 0800 - 0x00F0 0FFF)
0x0184 AE48 L1DMPPA18
L1D memory protection page attribute register 18 (controls memory address
0x00F0 1000 - 0x00F0 17FF)
0x0184 AE4C L1DMPPA19
L1D memory protection page attribute register 19 (controls memory address
0x00F0 1800 - 0x00F0 1FFF)
0x0184 AE50 L1DMPPA20
L1D memory protection page attribute register 20 (controls memory address
0x00F0 2000 - 0x00F0 27FF)
0x0184 AE54 L1DMPPA21
L1D memory protection page attribute register 21 (controls memory address
0x00F0 2800 - 0x00F0 2FFF)
0x0184 AE58 L1DMPPA22
L1D memory protection page attribute register 22 (controls memory address
0x00F0 3000 - 0x00F0 37FF)
0x0184 AE5C L1DMPPA23
L1D memory protection page attribute register 23 (controls memory address
0x00F0 3800 - 0x00F0 3FFF)
0x0184 AE60 L1DMPPA24
L1D memory protection page attribute register 24 (controls memory address
0x00F0 4000 - 0x00F0 47FF)
0x0184 AE64 L1DMPPA25
L1D memory protection page attribute register 25 (controls memory address
0x00F0 4800 - 0x00F0 4FFF)
0x0184 AE68 L1DMPPA26
L1D memory protection page attribute register 26 (controls memory address
0x00F0 5000 - 0x00F0 57FF)
0x0184 AE6C L1DMPPA27
L1D memory protection page attribute register 27 (controls memory address
0x00F0 5800 - 0x00F0 5FFF)
0x0184 AE70 L1DMPPA28
L1D memory protection page attribute register 28 (controls memory address
0x00F0 6000 - 0x00F0 67FF)
0x0184 AE74 L1DMPPA29
L1D memory protection page attribute register 29 (controls memory address
0x00F0 6800 - 0x00F0 6FFF)
