6.26.1 uPP Register Descriptions
Table 6-115. Universal Parallel Port (uPP) Registers
BYTE ADDRESS ACRONYM REGISTER DESCRIPTION
0x01E1 6000 UPPID uPP Peripheral Identification Register
0x01E1 6004 UPPCR uPP Peripheral Control Register
0x01E1 6008 UPDLB uPP Digital Loopback Register
0x01E1 6010 UPCTL uPP Channel Control Register
0x01E1 6014 UPICR uPP Interface Configuration Register
0x01E1 6018 UPIVR uPP Interface Idle Value Register
0x01E1 601C UPTCR uPP Threshold Configuration Register
0x01E1 6020 UPISR uPP Interrupt Raw Status Register
0x01E1 6024 UPIER uPP Interrupt Enabled Status Register
0x01E1 6028 UPIES uPP Interrupt Enable Set Register
0x01E1 602C UPIEC uPP Interrupt Enable Clear Register
0x01E1 6030 UPEOI uPP End-of-Interrupt Register
0x01E1 6040 UPID0 uPP DMA Channel I Descriptor 0 Register
0x01E1 6044 UPID1 uPP DMA Channel I Descriptor 1 Register
0x01E1 6048 UPID2 uPP DMA Channel I Descriptor 2 Register
0x01E1 6050 UPIS0 uPP DMA Channel I Status 0 Register
0x01E1 6054 UPIS1 uPP DMA Channel I Status 1 Register
0x01E1 6058 UPIS2 uPP DMA Channel I Status 2 Register
0x01E1 6060 UPQD0 uPP DMA Channel Q Descriptor 0 Register
0x01E1 6064 UPQD1 uPP DMA Channel Q Descriptor 1 Register
0x01E1 6068 UPQD2 uPP DMA Channel Q Descriptor 2 Register
0x01E1 6070 UPQS0 uPP DMA Channel Q Status 0 Register
0x01E1 6074 UPQS1 uPP DMA Channel Q Status 1 Register
0x01E1 6078 UPQS2 uPP DMA Channel Q Status 2 Register
