3.7.26 Reserved and No Connect
Table 3-30. Reserved and No Connect Terminal Functions
SIGNAL
TYPE
(1)
DESCRIPTION
NAME NO.
RSV2 T19 PWR
Reserved. For proper device operation, this pin must be tied either directly to
CVDD or left unconnected (do not connect to ground).
NC M3, M14, N16
Pin M3 should be left unconnected (do not connect to power or ground)
Pins M14 and N16 may be left unconnected or connected to ground (VSS)
