Table 5-4. LDO NVM Settings (continued)
Register Name Field Name
TPS65941120-Q1 TPS65941421-Q1
Value Description Value Description
LDO4_PG_WIND
OW
LDO4_OV_THR 0x3 +5% / +50 mV 0x3 +5% / +50 mV
LDO4_UV_THR 0x3 -5% / -50 mV 0x3 -5% / -50 mV
5.5 VCCA Settings
These settings detail the default monitoring enabled on VCCA. All these settings can be changed though I
2
C
after startup.
Table 5-5. VCCA NVM Settings
Register Name Field Name
TPS65941120-Q1 TPS65941421-Q1 LP876411B5-Q1
Value Description Value Description Value Description
VCCA_VMON_C
TRL
VMON_DEGLITC
H_SEL
0x1 20 us 0x1 20 us 0x1 VCCA 20us, VMON/
BUCK 20us
VCCA_VMON_E
N
0x1 Enabled; OV and UV
comparators.
0x1 Enabled; OV and UV
comparators.
0x1 Enabled; OV and UV
comparators.
VCCA_PG_WIND
OW
VCCA_OV_THR 0x7 +10% 0x7 +10% 0x7 +10%
VCCA_UV_THR 0x7 -10% 0x7 -10% 0x7 -10%
VCCA_PG_SET 0x0 3.3 V 0x0 3.3 V 0x0 3.3 V
GENERAL_REG
_1
FAST_VCCA_OV
P
0x0 slow, 4us deglitch filter
enabled
0x0 slow, 4us deglitch filter
enabled
GENERAL_REG
_3
LPM_EN_DISAB
LES_VCCA_VM
ON
0x1 VCCA_VMON enabled
if VCCA_VMON_EN=1
and LPM_EN=0
0x1 VCCA_VMON enabled
if VCCA_VMON_EN=1
and LPM_EN=0
0x1 VCCA_VMON enabled
if VCCA_VMON_EN=1
and LPM_EN=0
5.6 GPIO Settings
These settings detail the default configurations of the GPIO rails. All these settings can be changed though I
2
C
after startup. Note that the contents of the GPIOx_SEL field determine which other fields in the GPIOx_CONF
and GPIO_OUT_x registers are applicable. To understand which NVM fields apply to each GPIOx_SEL option,
see the Digital Signal Descriptions section in TPS6594-Q1 data sheet and LP8764-Q1 data sheet.
Table 5-6. GPIO NVM Settings
Register Name Field Name
TPS65941120-Q1 TPS65941421-Q1 LP876411B5-Q1
Value Description Value Description Value Description
GPIO1_CONF GPIO1_OD 0x0 Push-pull output 0x0 Push-pull output 0x0 Push-pull output
GPIO1_DIR 0x0 Input 0x0 Input 0x0 Input
GPIO1_SEL 0x1 SCL_I2C2/CS_SPI 0x0 GPIO1 0x0 GPIO1
GPIO1_PU_SEL 0x0 Pull-down resistor
selected
0x0 Pull-down resistor
selected
0x0 Pull-down resistor
selected
GPIO1_PU_PD_
EN
0x0 Disabled; Pull-up/pull-
down resistor.
0x1 Enabled; Pull-up/pull-
down resistor.
0x1 Enabled; Pull-up/pull-
down resistor.
GPIO1_DEGLITC
H_EN
0x0 No deglitch, only
synchronization.
0x1 8 us deglitch time. 0x1 8 us deglitch time.
GPIO2_CONF GPIO2_OD 0x0 Push-pull output 0x0 Push-pull output 0x0 Push-pull output
GPIO2_DIR 0x0 Input 0x0 Input 0x0 Input
GPIO2_SEL 0x2 SDA_I2C2/SDO_SPI 0x0 GPIO2 0x0 GPIO2
GPIO2_PU_SEL 0x0 Pull-down resistor
selected
0x0 Pull-down resistor
selected
0x0 Pull-down resistor
selected
GPIO2_PU_PD_
EN
0x0 Disabled; Pull-up/pull-
down resistor.
0x1 Enabled; Pull-up/pull-
down resistor.
0x1 Enabled; Pull-up/pull-
down resistor.
GPIO2_DEGLITC
H_EN
0x0 No deglitch, only
synchronization.
0x1 8 us deglitch time. 0x1 8 us deglitch time.
Static NVM Settings www.ti.com
20 TPS65941120-Q1, TPS65941421-Q1 and LP876411B5-Q1 PMIC User Guide
for J721S2, PDN-0A
SLVUCJ9 – FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
