Texi Iris 10 Operation Manual
18
Main functions on the LCD panel
After turning the machine on, user may proceed with the following operations by using the operation panel.
TEXI.DST
1 LED lamp switch ON/OFF LED lamp
2 Pattern preview zone Displays selected pattern, previews embroidery frame movement posi-
tion and embroidery progress
3 Button function zone General-purpose key, moves embroidery frame, sets machine parame-
ter, one-key frame movement, machine speed control etc.
4 Embroidery parameter dis-
play zone
Displays machine parameters, such as pattern name, embroidery nee-
dle number, embroidery frame type
5 Machine networking state
Displays machine software version, date, time, machine IP address
