14
Install the thread rack guide tube (1) on the thread base (2), and lock it with the guide tube nut (3).
1.Thread rack module and guide tube 2. Thread rack 3. Nut
Install the assembled thread rack (1) on the machine head on two positioning dowels, and tighten nut (2) with hex wrench, and
nut (3)
1. Thread rack 2. Positioning dowel 3. Screw
Installation of embroidery frame
Align the hole of embroidery frame (1) stand with the dowel on the connecting plate (2).
