2.03 Receipt Of Equipment
When you receive the equipment, check it against the invoice to make sure it is complete and inspect the equipment
for possible damage due to shipping. If there is any damage, notify the carrier immediately to file a claim. Furnish
complete information concerning damage claims or shipping errors to the location in your area listed in the inside
back cover of this manual.
Include all equipment identification numbers as described above along with a full description of the parts in error.
Move the equipment to the installation site before un-crating the unit. Use care to avoid damaging the equipment when
using bars, hammers, etc., to un-crate the unit.
2.04 Power Supply Specifications
A60i Power Supply Specifications
Input Power 208 - 480 VAC, Single Phase, 50/60 Hz
Input Power Cable
Power Supply includes 9' single phase 6AWG 3/C input cable with NEMA
6-50P Plug..
Output Current 10 - 60 Amps, Continuously Adjustable
Power Supply Gas
Filtering Ability
Particulates to 5 Microns
A60i Power Supply Duty Cycle *
Ambient
Temperature
Duty Cycle Ratings @ 40° C (104° F)
Operating Range 0° - 50° C
Rating
All Units
Duty Cycle 50% (208-230V ONLY) 80% 100%
Current
60 Amps 60 Amps 40 Amps
DC Voltage
132 132 119
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the output
voltage (DC) is higher than shown in this chart.
A60i
A40i Power Supply Specifications
Input Power 208 - 480 VAC, Single Phase, 50/60 Hz
Input Power Cable
Power Supply includes 9' single phase 8AWG
3/C input cable with NEMA 6-50P Plug..
Output Current 10 - 40 Amps, Continuously Adjustable
Power Supply Gas
Filtering Ability
Particulates to 5 Microns
A40i Power Supply Duty Cycle *
Ambient Temperature
Duty Cycle Ratings @ 40° C (104° F)
Operating Range 0° - 50° C
Rating
All Units
Duty Cycle 80% 100%
Current
40 Amps 30 Amps
DC Voltage
119 119
* NOTE: The duty cycle will be reduced if the primary input power (AC)
is low or the output voltage (DC) is higher than shown in this chart.
A40i
