PARTS LIST Manual 0-5466
6-6
6.07 Replacement Parts - for Machine Torches with Unshielded Leads
Item No. Qty Description Catalog No.
1 1 Torch Head Assembly without leads (includes items 2, 3, and 14) 9-8220
2 1 Large O-Ring 8-3487
3 1 Small O-Ring 8-3486
4 1 PIP Switch Kit 9-7036
5 Unshielded Automated Leads Assemblies with ATC connectors
1 5 - foot / 1.5 m Leads Assembly with ATC connector 4-7850
1 10 - foot / 3.05 m Leads Assembly with ATC connector 4-7851
1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-7852
1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-7853
6 Unshielded Mechanized Leads Assemblies with ATC connectors
1 5 - foot / 1.5 m Le-ads Assembly with ATC connector 4-7842
1 10 - foot / 3.05 m Leads Assembly with ATC connector 4-7843
1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-7844
1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-7845
7 1 11” / 279 mm Rack 9-7041
8 1 11” / 279 mm Mounting Tube 9-7043
9 1 End Cap Assembly 9-7044
10 2 Body, Mounting, Pinch Block 9-4513
11 1 Pin, Mounting, Pinch Block 9-4521
12 1 Torch Holder Sleeve 7-2896
13 1 PIP Plunger and Return Spring Kit 9-7045
1 Pinion Assembly (Not shown) 7-2827
1 5” / 126 mm Positioning Tube (Not shown) 9-7042
