A40i, A60i
Manual 0-5466 INSTALLATION
3-1
SECTION 3 SYSTEM:
INSTALLATION
3.01 Unpacking
1. Use the packing lists to identify and account for each item.
2. Inspect each item for possible shipping damage. If damage is evident, contact your distributor and / or
shipping company before proceeding with the installation.
3. Record Power Supply and Torch model and serial numbers, purchase date and vendor name, in the infor-
mation block at the front of this manual.
3.02 Lifting Options
The Power Supply includes handles for hand lifting only. Be sure unit is lifted and transported safely and securely.
WARNING
Do not touch live electrical parts.
Disconnect input power cord be-
fore moving unit.
FALLING EQUIPMENT can cause
serious personal injury and can
damage equipment.
HANDLES are not for mechanical
lifting.
• Only persons of adequate physical strength should lift the unit.
• Lift unit by the handles, using two hands. Do not use straps for lifting.
• Use optional cart or similar device of adequate capacity to move unit.
• Place unit on a proper skid and secure in place before transporting with a fork lift or other vehicle.
3.03 Power Supply location and Mounting
NOTE!
It is recommended that the unit be
secured to a suitable surface using the
mounting rails.
1. First choose an appropriate location for mounting the power supply. Choose one that allows for free move-
ment of torch leads, complies with ventilation per section 2.04 and provides a safe rm surface where the
unit can be secured.
2. Place the unit in the desired position and mark where the four keyway holes in the mounting rails touch.
3. Remove the unit and using these markings, prepare holes for mounting hardware.
4. Insert proper hardware. If using hardware that screws into the mounting surface, leave all four loose enough
for the thickness of the rail to slide under the head and washer if used.
5. Lower the power supply over the mounting hardware and slide forward or backward until the keyway stops
against the mounting hardware.
6. Secure the hardware to the rail.
