Manual 0-5466 INTRODUCTION
2-3
2.05 Input Wiring Specifications
A60i Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I
1
e
Fuse
(amps)
Flexible Cord (Min.
AWG)
1 Phase
208 50/60 9.4 45.0 40.1 50 6 AWG (16 mm2)
230 50/60 9.4 40.8 36.3 50 8 AWG 10 mm2)
480 50/60 9.4 19.5 17.3 30 12 AWG (4 mm2)
3 Phase
208 50/60 9.8 27.3 24.3 50 8 AWG 10 mm2)
230 50/60 9.7 24.5 21.8 50 10 AWG (6 mm2)
380 50/60 9.5 14.5 12.9 30 14 AWG (2.5 mm2)
400 50/60 9.6 13.8 12.3 30 14 AWG (2.5 mm2)
415 50/60 9.6 13.4 11.9 30 14 AWG (2.5 mm2)
480 50/60 9.8 11.8 10.5 20 14 AWG (2.5 mm2)
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
A40i Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I
1
eff Fuse (amps)
Flexible Cord (Min.
AWG)
1 Phase
208 50/60 5.6 27.1 24.1 50 10 AWG (6 mm2)
230 50/60 5.6 24.5 21.8 50 12 AWG (4 mm2)
480 50/60 5.6 11.7 10.4 20 16 AWG (1.5 mm2)
3 Phase
208 50/60 5.9 16.4 14.6 25 12 AWG (4 mm2)
230 50/60 5.8 14.7 13.1 25 14 AWG (2.5 mm2)
380 50/60 5.7 8.7 7.7 15 16 AWG (1.5 mm2)
400 50/60 5.7 8.3 7.4 15 16 AWG (1.5 mm2)
415 50/60 5.8 8.0 7.2 15 16 AWG (1.5 mm2)
480 50/60 5.9 7.1 6.3 15 16 AWG (1.5 mm2)
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTE!
Refer to Local and National Codes or local authority having jurisdic-
tion for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
