A40i, A60i
OPERA
TION
Manual 0-5466
4-6
Select Cutting Mode
1
2
Art # A-13251
1.
Press and release the upper knob without turning to enter the mode selection menu. Place the system in
one of the four cutting modes available by pressing and r
eleasing the knob until you reach the desir
ed
mode.:
RUN
LA
TCH .
RAPID AUT
O REST
ART
GOUGE
SET/PURGE (gas flow only)
MARKING
2.
After selecting the cutting mode, set the output current by turning the knob.
Set T
orch Parameters
1.
Press and release the bottom knob without r
otating to enter the torch type and leads length selections.
39
41
