Manual 0-4998 5-11 SERVICE
• Pilot Arc re-ignites immediately
11. Open the torch switch
• DC LED turns off
After 20 second post flow time
• Gas solenoid closes
• Gas flow stops
For Automation Torches - Skip steps 12 & 13
12. Set the FUNCTION CONTROL SWITCH to
LATCH mode
13. Start a cut, and remove the START signal.
• Main cutting arc will remain on until the torch
is lifted away from the plate approx ¾” or until
the torch is brought off the edge of the metal
Once the arc has extinguished
• DC LED turns off
After 20 second post flow time
• Gas solenoid closes
• Gas flow stops
• Ten (10) minutes after the Start signal is re-
moved, the cooling fans turn off.
This completes the Main Arc and Controls Test. If the
above are all correct then proceed to the next section
"H CNC Interface Test." If the unit does not function as
stated above, then note the symptom and proceed to
Section "5.09, Main Arc and Controls Problems".
H. CNC INTERFACE TEST
If the unit has one of the two factory supplied options
for CNC interface installed, proceed with this section,
otherwise the tests are complete.
1. Connect an ohmmeter between J2-12 to J2-14
(START signal). Position the torch to pilot. Check
the OK-TO-MOVE signal by connecting a jumper
between J2-3 and J2-4 (START signal).
• Pilot arc is established
2. Bring the torch to the work piece and transfer to
cutting arc.
• OK-TO-MOVE signal is present. (Meter shows
continuity)
3. Remove jumper from J6.
• OK-TO-MOVE signal off (Meter shows no
continuity)
• Gas continues to flow
• DC LED goes off
After 20 second Post flow time
• Gas solenoid closes
• Gas flow stops
If the unit has the Basic CNC Interface harness the
test is complete. If the unit does not function as
stated above, then note the symptom and proceed
to Section "5.10 CNC Interface Problems".If the unit
has the Automation Interface PCB installed, continue
with this section.
4. There are three (3) ARC VOLTs signals available
from the J6 connector.
a) J2-9 (+) to J2-7 (-)
b) J2-5 (+) to J2-6 (-) (Auto Interface pcb J3 con-
nector with jumper installed between pins 1
and 2) = ARC VOLTS divided by 50
c) J2-5 (+) to J2-6 (-) (Auto Interface pcb J3 con-
nector with jumper installed between pins 2
and 3) = ARC VOLTS divided by 16
Measure the voltage between these points while pi-
loting (Open Circuit Voltage) and while cutting. The
voltages should approx as listed below
Open Circuit Voltage Cutting Voltage
a) 300 VDC 100 VDC
b) 6 VDC 2 VDC
c) 19 DVC 6 VDC
