Thermal Dynamics CUTMASTER User Manual

CUTMASTER 35mm, 40mm
INTRODUCTION 2-2 Manual 0-5118
2.04 Power Supply Specifications
CutMaster 35 Power Supply Specifications
380 VAC (360 - 440 VAC), Three Phase, 50/60 Hz
400 VAC (360 - 440 VAC), Three Phase, 50/60 Hz
Input Power Cable
Power Supply includes input cable.
Output Current
30 - 100 Amps, Continuously Adjustable
Power Supply Gas
Filtering Ability
Particulates to 5 Microns
CutMaster 35 Power Supply Duty Cycle *
Ambient Temperature
Duty Cycle Ratings @ 40° C (104° F)
Opperating Range 0° - 50° C
All Units
Duty Cycle
60% 80%
100%
Current
100 80 70
IEC
IEC IEC
DC Voltage
120 120 116
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the
output voltage (DC) is higher than shown in this chart.
CutMaster 40 Power Supply Specifications
380 VAC (360 - 440 VAC), Three Phase, 50/60 Hz
400 VAC (360 - 440 VAC), Three Phase, 50/60 Hz
Input Power Cable
Power Supply includes input cable.
Output Current
30 - 120 Amps, Continuously Adjustable
Power Supply Gas
Filtering Ability
Particulates to 5 Microns
CutMaster 35 Power Supply Duty Cycle *
Ambient Temperature
Duty Cycle Ratings @ 40° C (104° F)
Opperating Range 0° - 50° C
All Units
Duty Cycle
N/A 80% 100%
Current
120 100
IEC IEC IEC
DC Voltage
128 124
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the
output voltage (DC) is higher than shown in this chart. **Using a 208/230 VAC input will
reduce this duty cycle to 50%
NOTE
IEC Rating is determined as specified by the International Electro-Technical Commission. These specifications
include calculating an output voltage based upon power supply rated current. To facilitate comparison between
power supplies, all manufacturers use this output voltage to determine duty cycle.
