Thermal Dynamics CUTMASTER User Manual

CUTMASTER 35mm, 40mm
Manual 0-5118 6-1 PARTS LIST
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as follows:
Section 6.03 Complete Power Supply Replacement
Section 6.04 Replacement Parts
Section 6.05 Options and Accessories
Section 6.06 Replacement Parts for Hand Torch
Section 6.07 Replacement Parts - for Machine Torches with Unshielded Leads
Section 6.08 Replacement Shielded Machine Torch Leads Assemblies
Section 6.09 Torch Consumable Parts (SL100)
NOTE
Parts listed without item numbers are not shown, but may be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper autho-
rization will not be accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in the
parts list for each type item. Also include the model and serial number of the power supply. Address all inqui-
ries to your authorized distributor.
6.03 Power Supply Replacement
The following items are included with the replacement power supply: work cable & clamp, input power cable,
gas pressure regulator / filter, and operating manual.
Qty Description Catalog #
1 CutMaster 35mm Non CE Power Supply
with 400VAC, 3 phase input power cable 3-1330-3
1 CutMaster 40mm Non CE Power Supply
with 400VAC, 3 phase input power cable 3-1730-3
1 CutMaster 35mm CE Power Supply
with 400VAC, 3 phase input power cable 3-1330-4
1 CutMaster 40mm CE Power Supply
with 400VAC, 3 phase input power cable 3-1730-4
