Mechanized Torch Operation
For optimum smooth surface quality, the travel
speed should be adjusted so that only the leading
edge of the arc column produces the cut. If the
travel speed is too slow, a rough cut will be pro-
duced as the arc moves from side to side in search
of metal for transfer.
Travel speed also affects the bevel angle of a cut.
When cutting in a circle or around a corner, slow-
ing down the travel speed will result in a squarer
cut. The power source output should be reduced
also. Refer to the appropriate Control Module
Operating Manual for any Corner Slowdown
adjustments that may be required.
Piercing With Machine Torch
To pierce with a machine torch, the arc should
be started with the torch positioned as high as
possible above the plate while allowing the arc
to transfer and pierce. This standoff helps avoid
having molten metal blow back onto the front end
of the torch.
When operating with a cutting machine, a pierce or
dwell time is required. Torch travel should not be
enabled until the arc penetrates the bottom of the
plate. As motion begins, torch standoff should be
reduced to the recommended 1/8 - 1/4 inch (3-6
mm) distance for optimum speed and cut quality.
Clean spatter and scale from the shield cup and the
tip as soon as possible. Spraying or dipping the
shield cup in anti - spatter compound will mini-
mize the amount of scale which adheres to it.
