Thermal Dynamics CUTMASTER User Manual

CUTMASTER 35mm, 40mm
Manual 0-5118 4T-17 OPERATION
Type Torch: SL100 With Shielded Tip Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4
9-8212
124
100
110
2.80
0.180
4.6 75 5.2 130 390
0.4 0.200
5.1
0.375 9.5
9-8212
127
100
75
1.90
0.180
4.6 75 5.2 130 390
0.5 0.200
5.1
0.500 12.7
9-8212
132
100
50
1.30
0.180
4.6 75 5.2 130 390
0.6 0.200
5.1
0.625 15.9
9-8212
136
100
30
0.75
0.180
4.6 75 5.2 130 390
0.8 0.200
5.1
0.750 19.0
9-8212
140
100
18
0.45
0.190
4.8 75 5.2 130 390
2.0 0.225
5.7
1.000 25.4
9-8212
147
100
10
0.25
0.190
4.8 75 5.2
130
390
NR NR
NR
Type Torch: SL100 With Shielded Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250
6.4 9-8212
121 100 110
2.80
0.125
3.2 75 5.2 130 390
0.5 0.200
5.1
0.375
9.5 9-8212
125 100 60
1.50
0.150
3.8 75 5.2 130 390
0.8 0.200
5.1
0.500
12.7 9-8212
132 100 35
0.90
0.150
3.8 75 5.2 130 390
1.0 0.200
5.1
0.625
15.9 9-8212
137 100 20
0.50
0.150
3.8 75 5.2 130 390
2.0 0.225
5.7
0.750
19.0 9-8212
144 100 15
0.40
0.190
4.8 75 5.2 130 390
NR NR
NR
1.000
25.4 9-8212
154 100 8
0.20
0.190
4.8 75 5.2 130 390
NR NR
NR
Type Torch: SL100 With Shielded Tip
Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250
6.4 9-8212
120
100
120
3.05
0.180
65 4.5 105 360
0.2 0.225
5.7
0.375
9.5 9-8212
128
100
65
1.65
0.180
65 4.5 105 360
0.4 0.225
5.7
0.500
12.7 9-8212
130
100
45
1.15
0.180
65 4.5 105 360
0.5 0.225
5.7
0.625
15.9 9-8212
135
100
30
0.75
0.180
65 4.5 105 360
0.8 0.225
5.7
0.750
19.0 9-8212
140
100
25
0.65
0.180
65 4.5 105 360
1.0 0.225
5.7
1.000
25.4 9-8212
148
100
10
0.25
0.190
65 4.5
105 360 NR NR
NR
NOTES
* Gas pressure shown is for torches with leads up to 25’ / 7.6 m long. For 50’ / 15.2 m leads, refer to section
4.02 "Operating Pressure".
** Total flow rate includes plasma and secondary gas flow.
