Manual 0-2569 61 PARTS LISTS
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provides a breakdown of all basic replace-
able parts. The parts lists are arranged as follows:
Section 6.03: External Power Supply Replacement
Parts List
Section 6.04: Access Panel Replacement Parts
Section 6.05: Front Panel/Chassis Replacement
Parts
Section 6.06: Rear Panel Replacement Parts
Section 6.07: Base Assembly Replacement Parts
Section 6.08: Upper Chassis Replacement Parts
Section 6.09: Main Heatsink Assembly Replacement
Parts
Section 6.10: Power Supply Options And
Accessories
NOTE
Parts listed without item numbers are not illus-
trated, but may be ordered by the catalog numbers
shown.
B. Returns
If a Thermal Dynamics product must be returned for ser-
vice, contact your Thermal Dynamics distributor. Mate-
rials returned to Thermal Dynamics without proper au-
thorization will not be accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete
description of the part or assembly, as listed in the de-
scription column of the Parts List. Also include the model
and serial number of the machine as shown on the data
tag attached to the unit. Address all inquiries to your au-
thorized Thermal Dynamics distributor.
