Thermal Dynamics MERLIN 6000 Service Manual

Manual 0-2569 91 APPENDIX
APPENDIX XIV: OK-TO-MOVE CIRCUIT DIAGRAM
A-01081
PIERCE
DELAY
0 - 3 seconds
OFF = OK-To-Move
24 VAC Source
Merlin 3000 or Merlin 6000 or Merlin 6000GST with
Remote Control RC6010 / Standoff Control SC10
OK-To-Move Circuit
OK
Logic PCB
J2-14
J2-16
J15-11
J15-10 J42-12
J42-14
OK PS
D82
OK OUT
D37
Pierce Delay
0 - 3 Seconds
OK
Standoff Control SC11
K12
OK
+
J11-7
J11-6
E1
J8-24
J40-14
J11-5
J40-12
J8-22
J11-8
A-01082
24VAC Source
K12 Energized prior to
and during pierce delay
TB2-9
TB2-10
Merlin 3000, 6000
or 6000GST
