Manual 0-2470 13 INSTALLATION
3.01 UNPACKING
Each component of the system is packaged separately and pro-
tected with a carton and packing material to prevent damage
during shipping.
Included with each power supply is:
(1) Work Cable with Clamp (Attached)
(1) 230V Single-Phase Input Power Cable with Plug (Optional)
(1) Air Q/D Coupling - 1/4 NPT to #6 Barb ..........Cat. No. 9-6258
(1) Fuse - 2 Amp, 600V ...............................................Cat. No. 9-3861
(1) Spare Parts Container (without Parts) ...............Cat. No. 8-3213
(1) Pak Master 50 Instruction Manual .....................Cat. No. 0-2470
Included with each machine torch system is:
(1) Remote Control Hand Pendant ..........................Cat. No. 7-3114
(1) Remote Control Interface Wire Harness ...........Cat. No. 9-6210
Torches are packaged separately. Included with each torch is:
(1) PCH/M-35 Torch (with Shield Cup, Tip, Electrode, and Gas
Distributor Installed)
(1) Torch Leads with Quick Disconnect (Attached)
(1) Torch Handle Assembly (For Hand Torches), or
(1) Machine Torch Mounting Assembly (For Machine Torches)
(1) MaximumLife™ Cutting Spare Parts Kit - Includes:
(1) Shield Cup Attachment .................................Cat. No. 9-6503
(5) Tips (Standoff Cutting) .................................Cat. No. 9-6500
(3) Tips (Drag Cutting)........................................Cat. No. 9-6501
(5) Electrodes ........................................................Cat. No. 9-6506
(1) Gas Distributor ...............................................Cat. No. 9-6507
Other accessories are packaged separately.
1. Unpack each item and remove all packing material.
2. Locate the packing list(s) and use the list to identify and
account for each item.
3. Inspect each item for possible shipping damage. If damage is
evident, contact your distributor and/or shipping company
before proceeding with system installation.
What's Included with
the Power Supply
What's Included
with the Torch
Unpacking Procedure
SECTION 3: INSTALLATION
