Manual 0-2470 27 OPERATION
4.01 OPERATING CONTROLS
Figure 4-A Operating Controls (See Table 4-A, page 28)
40
20
100
80
60
2
1
34
5
6
bar
psi
WORK
TORCH
ON
OFF
AC TEMP PIP GAS DC PILOT
CSD
GAS PRESSURE
CURRENT
RUN
SET
RUN/SET Switch
ON/OFF Switch
AC Indicator
TEMP Indicator
PIP (Parts-In-Place) Indicator
CSD Control
Current Control
PILOT Indicator
DC Indicator
GAS Indicator
WORK Cable
Gas Pressure Gauge
Gas Pressure Control
TORCH Receptacle
SECTION 4: OPERATION
