Manual 0-2470 19 INSTALLATION
3. Inside the power supply, locate the white 6-pin connector J7
on the top panel, close to the “REMOTE CONTROL” hole
location.
4. Connect the 6-pin plug on the remote control wire harness to
the 6-pin connector J7.
5. Locate the ground stud on the RIGHT side of the rear panel,
inside the panel, at approximate center height. Connect the
ground wire of the remote control wire harness to the ground
stud.
Do not ground the remote control wire harness to the system
ground stud, which is visible on the top panel of the power
supply.
6. Using the four #6-32 screws with locknuts, install the remote
control receptacle (J24) in the rear panel (position the recep-
tacle in the hole from INSIDE the unit).
7. Before reassembling the power supply enclosure, check that
all wire harnesses and ribbon cables are properly located in
the notches of the top and middle panels.
8. Position the unit in an upright position. Tip the unit and slide
one of the case halves onto the chassis. Then lift the unit and
set it down on its side with the case half down.
9. Before installing the other case half, make sure the edges of
the bottom, middle, and top chassis panels are fully inserted
into the slots in the case. Look for gaps between the front and
rear panels and the edge of the case. Look into the case to see
that the notches in the top corners of the front and rear panels
are flush against the plastic stops of the case. Some lifting and
re-settling of the chassis may be required to get all compo-
nents aligned correctly.
10. Gently lower the other half of the enclosure onto the other
side of the chassis by tipping it slightly so that the top is
slightly lower than the bottom. Then push and gently tap
down until the two case halves are within l/16 inch. (If you
have trouble getting the case halves close enough, remove the
top half and check to see that the bottom half is fully engaged
and that there are no wires out of place on the top and middle
panels.
11. Install the eight screws, lockwashers and nuts to complete the
assembly.
Install the Wire Harness
CAUTION
Reassemble the
Enclosure
3.05 REMOTE CONTROL HARNESS INSTALLATION (continued)
