TK 56704-1-OP-EN
37
keys are being pressed on the HMI Control Panel, the engine will not preheat
and start until 10 seconds after the last key is pressed.
NNoottee:: If the unit is equipped with optional Electric Standby, there may be
some additional prompts before the engine will start. Refer to Starting
the Electric Motor for details.
When the engine is preparing to start, the HMI Control Panel will display the
engine start screen (Figure 33, p. 37). The preheat buzzer sounds during the
engine preheat and crank sequence.
Figure 33. Engine Start Screen
After the engine is started, the display returns to the Standard Display of
temperature and setpoint.
Starting the Electric Motor
NNoottee:: Units equipped with the Electric Standby option only.
CCAAUUTTIIOONN
RRiisskk ooff IInnjjuurryy!!
The motor may start automatically any time the unit is turned on.
OOppeerraattiinngg IInnssttrruuccttiioonnss ffoorr PPrreemmiiuumm HHMMII CCoonnttrrooll PPaanneell
