50
TK 56704-1-OP-EN
DDiieesseell MMooddee MMeennuu:: If a unit equipped with electric standby is running in
electric mode and the Electric to Diesel Auto-switch feature is set NO, this
feature allows the operator to manually select diesel mode operation. This
feature does not appear if the unit does not feature optional Electric Standby
or if the Electric to Diesel Auto-switch feature is set YES.
AAddjjuusstt BBrriigghhttnneessss MMeennuu:: Allows the operator to adjust the HMI Control
Panel display backlight intensity as required by local conditions.
TTiimmee MMeennuu:: Allows the operator to view the unit time and date. The time
and date cannot be changed from this menu.
Languages Menu
If the Language feature is enabled, an alternate language can be selected
from the Language Menu. After a new language is chosen, all subsequent
displays will appear in that language. If the language feature is not enabled,
this menu does not appear. The default language is English. Only languages
that have been enabled in Guarded Access will appear. Exercise care when
changing languages, once changed, all HMI Control Panel displays will be in
the new language. If the user is not familiar with the new language,
problems may be experienced returning to the default language.
MMiixx aanndd MMaattcchh LLaanngguuaaggee FFeeaattuurree:: Software revision 68xx allows any five
languages from both the 65/75xx and 66/76xx to be enabled. Japanese and
Chinese are not available for use with this feature.
NNoottee:: WinTrac 4.8.1 or later is required to use the Mix and Match Language
Feature.
To select an alternate language, press the MENU key.
Figure 54. Menu Key
If enabled, the Language Menu is the first menu item to appear as shown
(Figure 55, p. 51). Press the SELECT key to choose the Language menu.
OOppeerraattiinngg IInnssttrruuccttiioonnss ffoorr PPrreemmiiuumm HHMMII CCoonnttrrooll PPaanneell
