TK 56704-1-OP-EN
49
languages are available. English is the default language and is provided in
each of the packages.
AAllaarrmmss MMeennuu:: Allows the operator to view all alarms, and allows most
alarms to be cleared. If only one language is enabled, this will be the first
menu item to appear.
GGaauuggeess MMeennuu:: Allows the operator to view the unit gauges and the state of
the Inputs and Outputs on both the Interface Board and the Expansion
Module.
SSeennssoorrss MMeennuu:: Allows the operator to view the unit temperature sensors. If
a DAS Data Logger is installed, the data logger sensors may also be viewed.
DDaattaa LLooggggeerr MMeennuu:: Allows the operator to send a Start of Trip marker to the
ServiceWatch Data Logger and the optional DAS Data Logger (if installed). A
Print request can also be sent to the optional DAS Data Logger (if installed)
to print the most recent trip record.
HHoouurrmmeetteerrss MMeennuu:: Allows the operator to view the unit hourmeters that
have the view feature enabled in the Guarded Access Menu. If the view
feature for a particular hourmeter is not enabled, that hourmeter will
continue to accumulate time but cannot be viewed from the Main Menu.
However, all hourmeters can be viewed from the Maintenance Menu, even if
they are not enabled.
MMooddee MMeennuu:: Allows the operator to change the unit operating modes if
allowed. Not all modes may appear depending on the settings selected from
the Guarded Access menu and the HMI Control Panel software version.
• Turn Off CYCLE-SENTRY Mode/Turn On CYCLE-SENTRY Mode (If CYCLE-
SENTRY is Off unit runs in Continuous).
• Allows Temperature Units to be selected as Fahrenheit or Celsius.
• Allows Single Zone Control or Multi Zone Control to be selected.
• Allow Keypad Lock-Out to be selected.
• Allows Sleep Mode to be entered.
PPrreettrriipp MMeennuu:: Allows the operator to start a Pretrip Test. If an alarm is
active, the Pretrip Test is not allowed and the operator is prompted to clear
the alarm(s).
EElleeccttrriicc SSttaannddbbyy MMeennuu:: If the Electric Standby option is present and the
Diesel to Electric Auto-switch feature is set NO, this feature allows the
operator to manually select electric mode operation. This feature does not
appear if the unit does not feature optional Electric Standby or if the Diesel to
Electric Auto-switch feature is set YES.
OOppeerraattiinngg IInnssttrruuccttiioonnss ffoorr PPrreemmiiuumm HHMMII CCoonnttrrooll PPaanneell
