48
TK 56704-1-OP-EN
DDaattaa LLooggggeerr SSeennssoorr 66 TTeemmppeerraattuurree:: Displays the temperature of the Data
Logger sensor 6.
Using The Main Menu
The Main Menu contains several additional submenus that allow the
operator to view information and modify unit operation. To access the Main
Menu press the MENU key.
Figure 52. Menu Key
The first Main Menu choice will appear. Press the NEXT and BACK keys to
scroll through the menu choices. When the desired selection is shown on the
display, press the SELECT key to access it. The Pretrip submenu is shown
(Figure 53, p. 48). To return to the Standard Display press the EXIT key.
Figure 53. Pretrip Submenu
Main Menu Choices
LLaanngguuaaggee MMeennuu:: If more than one language is enabled, this will be the first
menu item to appear. If only one language is enabled, this menu will not
appear. The Language Menu allows the operator to select a language from a
list of up to 11 languages at one time. All subsequent displays are shown in
the selected language. Three different language packages with a total of 23
OOppeerraattiinngg IInnssttrruuccttiioonnss ffoorr PPrreemmiiuumm HHMMII CCoonnttrrooll PPaanneell
