Thermo King T-1090 SPECTRUM User Manual

TK 56704-1-OP-EN
95
Fuse
Size Function
F10 10A
8X Power (Install fuse in right position)
F11 None No Fuse
F12 5A 2A Power to CAN Connector J13
F13 2A
8FC Circuit (Remote Status Light/Optional
Power)
F20 2A Alternator Sense
F21 60A Main Fuse (2 Circuit)
F25 7.5A HPCO Switch Circuit
F26 5A Power to CAN Connector J98
F10 When fuse F10 is installed in the right position the On/Off keys on the HMI turn the unit
on and off. When fuse F10 is installed in the left position the unit will start and run without
the HMI controller.
Electric Standby Specifications (SmartPower™
Model 50 Units)
Electric Motor and Overload Relay
T-1090 and T-1090 SPECTRUM
Voltage/
Phase/
Frequency
Horse-
power
Kilowatts
RPM
Full Load
(amps)
Overload
Relay
Setting
(amps)
230/3/50 10.0 7.5 1460 25.3 38
200-230/3/60 12.0 8.9 1750 28.8 38
400/3/50 10.0 7.5 1460 13.90 19
460/3/60 12.0 8.9 1750 14.4 19
