Product overview
9
1.2󳒀 Part names
1.2.1󳒀 Front camera (main unit) - front view
Fixing bracket connector
Used to connect the fixing bracket.
V-IN input port
Used to connect the rear camera.
GPS connector
Used to connect the external GPS module
(optional) for additional features.
DC-IN power connector
Used to connect the power cable.
Front camera lens
Records the front view.
Security LED
Indicates that the video is being recorded.
Speaker
Outputs the voice guide and buzzer
sounds to indicate the product’s status.
Power switch
•󳒀 Slide down to turn on the
product.
•󳒀 Slide up to turn off the
product.
Memory card slot
Insert a memory card to
save recordings
