Removal (cont’d)
8 Disconnect the air filter restrictor sensor wires locat-
ed at the rear of the air cleaner canister.
9 Remove the exhaust system from the loader. Cover
or plug any open exhaust ports to the engine.
7-16
C3582
C3625
C3632
12 Remove the ground wires from the chassis ground
bolt. Disconnect the wires going to the fuel level sender
in the fuel tank. (fig. C3582)
11 Disconnect the hoses going to the coolant over flow
tank, or remove the bolts holding the tank to the loader
frame. (fig. C3625)
10 Remove the air cleaner canister assembly. (fig.
C3632). Plug or cover any open air lines to prevent conta-
mination.
Fuel sender wires
Coolant over flow tank
ENGINE REPLACEMENT 7.3
Air Cleaner Canister
To Next Page
