39
2. Oil Level Check
To check the oil level, stop the engine with the loader on
level ground, open the rear door and remove the dipstick
(Fig. 4. 7B1).
Keep the oil level between the full and low mark on the
dipstick (Fig. 4. 7B2). Do not fill above the full mark and
use only appropriat oil (See Section 5 for specifications).
3. Engine Oil and Filter Replacement
Operate the engine until warm, approximately 5 minutes.
Stop the engine.
Remove the cap on the oil drain hose located at the bottom
of the oil pan. (Fig 4. 7C1).
Remove the oil filter (Fig. 4. 7C2). Clean the filter housing
surface. Put clean oil on the seal of the new filter and
install the filter hand tight. Replace the oil drain plug.
Remove the filler cap and add appropriate engine oil (See
Section 5 for specifications). Start the engine and run for 5
minutes. Stop the engine and check for leaks at the filter.
Recheck the oil level and add oil until the level is at the top
mark on the dipstick.
Oil Check Daily
Oil Change 150 hrs.
Filter Change 150 hrs.
Engine Oil Drain
C-842
Fig. 4.7C1
4...MAINTENANCE
C-642
fig. 47B2
C-894
FIG 4.7C2
FIG 4.7.B1
C-880
Engine Oil Filter
Engine Fuel Filter
