2. Battery Access
The battery is located behind the LH transmission, in the
engine compartment ( See Fig. 4. 9B1 & B2)).
4...MAINTENANCE
WARNING
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked. Then,
unlatch the seat belt and exit
the loader. Do not enter or
exit with the engine running
unless as specified in this
manual or under specific
service and backhoe
operating procedures.
Fig 4.9B1
C-895
Fig 4.9B2
C-1004
Battery
