4| Monitoring and Diagnostics
For example, the GetParameterValuesResponse (message 2 in preceding illustration) contains, amongst
others, following name-value pairs in its ParameterList argument:
WLAN statistics
The object “InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.“ is relevant to the WLAN statistics.
This object on the Thomson Gateway contains following vendor specific parameters:
 X_000E50_ChannelMode: this parameter can be used to request automatic selection of the channel. The
parameter has one of the following values:
 Auto (default value)
 Manual
To retrieve the WLAN statistics, the GetParameterValues RPC (message 1 in preceding illustration) contains
following ParameterNames argument:
For example, the GetParameterValuesResponse (message 2 in preceding illustration) contains, amongst
others, following name-value pairs in its ParameterList argument:
Name Value
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.Enable 1
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.Status Up
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.UpstreamCurrRate 832
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.DownstreamCurrRate 8128
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.UpstreamMaxRate 1024
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.DownstreamMaxRate 8224
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.UpstreamNoiseMargin 60
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.DownstreamNoiseMargin 78
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.UpstreamAttenuation 0
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.DownstreamAttenuation 0
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.ShowtimeStart 19760
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.X_000E50_NumberOfResets 1
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.Stats.ShowTime.
X_000E50_LossOfSignal
0
InternetGatewayDevice.WANDevice.1.WANDSLInterfaceConfig.Stats.ShowTime.
X_000E50_LossOfPower
0
Entry Value
1 InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.
Name Value
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.Enable 1
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.Status Up
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.BSSID 00:14:7f:0e:14:fc
