Gateway LAN side IP addresses and DHCP pool configuration
The object “InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.“ is relevant to the LAN side
configuration information.
This object contains no vendor specific parameters.
To retrieve the gateway LAN side IP addresses and the DHCP pool configuration, the GetParameterValues
RPC (message 1 in preceding illustration) contains following ParameterNames argument:
For example, the GetParameterValuesResponse (message 2 in preceding illustration) contains, amongst
others, following name-value pairs in its ParameterList argument:
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.MaxBitRate Auto
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.Channel 11
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.
X_000E50_ChannelMode
Auto
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.SSID SpeedTouchEF5A50
InternetGatewayDevice.LANDevice.1.WLANConfiguration.1.BeaconType None
Name Value
Entry Value
1 InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.
Name Value
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.DHCPServerEnable 1
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.DHCPRelay 0
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.MinAddress 192.168.1.64
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.MaxAddress 192.168.1.253
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.SubnetMask 255.255.255.0
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.DomainName lan
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.IPRouters 192.168.1.254
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.DHCPLeaseTime 86400
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.
IPInterfaceNumberOfEntries
2
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.IPInterface.1.
IPInterfaceIPAddress
10.0.0.138
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.IPInterface.1.
IPInterfaceSubnetMask
255.255.255.0
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.IPInterface.2.
IPInterfaceIPAddress
192.168.1.254
InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.IPInterface.2.
IPInterfaceSubnetMask
255.255.255.0
