4| Monitoring and Diagnostics
TCP and UDP statistics
The object “InternetGatewayDevice.X_000E50_Connection.“ is a proprietary data model. This object can be
used to obtain statistics on current TCP and UDP connections.
To obtain these statistics, the GetParameterValues RPC (message 1 in preceding illustration) contains
following ParameterNames argument:
For example, the GetParameterValuesResponse (message 2 in preceding illustration) contains, amongst
others, following name-value pairs in its ParameterList argument:
Entry Value
1 InternetGatewayDevice.X_000E50_Connection.Stats.
Name Value
InternetGatewayDevice.X_000E50_Connection.Stats.Multicast 2
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.TCP 112
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.UDP 1
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.ICMP 0
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.Other 3
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.TCP.TCPOpen 0
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.TCP.TCPEstablished 0
InternetGatewayDevice.X_000E50_Connection.Stats.Protocol.TCP.TCPClosing 112
