THOMSON TR-069 - Page 90

E-DOC-CTC-20071119-0003 v1.0
84
6| Service Provisionin
g
 Finding the new chain: the Thomson Gateway automatically creates a new chain that is used by the new
security level. The GetParameterValues RPC (message 7 in preceding illustration) contains following
ParameterNames argument:
The GetParameterValuesResponse (message 8 in preceding illustration) contains for example value
“InternetGatewayDevice.X_000E50_Firewall.Chain.20”.
 Creating a rule: the AddObject RPC (message 9 in preceding illustration) contains for the ObjectName
argument the value “InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.”.
The AddObjectResponse (message 11 in preceding illustration) contains for the InstanceNumber
argument for example value “1“.
 Configuring the rule: the SetParameterValues RPC (message 12 in preceding illustration) contains
following name-value pairs in its ParameterList argument:
 Activating the security level: the SetParameterValues RPC (message 15 in preceding illustration)
contains following name-value pair in its ParameterList argument:
Entry Value
1 InternetGatewayDevice.X_000E50_Firewall.Level.7.Chain
Name Value
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
Description
“This is a test rule”
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
SourceInterface
InternetGatewayDevice.
LANDevice.1
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
Protocol
17 (6=TCP, 17=UDP,...)
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
DestinationPort
67
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
DestinationPortRangeEnd
67
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
DestinationPortExclude
0 (0=disabled, 1=enabled)
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
Tar get
Drop (Drop or Accept)
InternetGatewayDevice.X_000E50_Firewall.Chain.20.Rule.1.
Enable
1 (1=enabled, 0=disabled)
Name Value
InternetGatewayDevice.X_000E50_Firewall.SelectedLevel InternetGatewayDevice.
X_000E50_Firewall.Level.7
