6| Service Provisioning
Message flow
Following illustration shows a possible message flow for configuration of the GnuDIP service:
Example: parameter values
For example, following parameter values can be used:
 Configuring the service: the SetParameterValues RPC (message 1 in preceding illustration) contains
following name-value pairs in its ParameterList argument:
 Creating a client: the AddObject RPC (message 4 in preceding illustration) contains for the ObjectName
argument the value “InternetGatewayDevice.Services.X_000E50_DynamicDNS.Client.”.
The AddObjectResponse (message 6 in preceding illustration) contains for the InstanceNumber
argument for example value “1”.
ACSCPE
Transaction session
2) Apply changes
Configure the Service
1) SetParameterValues
3) SetParameterValuesResponse
...
8) Apply changes
Configure the Client
7) SetParameterValues
9) SetParameterValuesResponse
Create a Client
4) AddObject
6) AddObjectResponse
5) Apply changes
Create a Host
10) AddObject
12) AddObjectResponse
11) Apply changes
14) Apply changes
Configure the Host
13) SetParameterValues
15) SetParameterValuesResponse
17) Apply changes
Activate the Client
16) SetParameterValues
18) SetParameterValuesResponse
...
Name Value
InternetGatewayDevice.Services.X_000E50_DynamicDNS.Service.
6.Server
dns-atm.dyndns.sit
InternetGatewayDevice.Services.X_000E50_DynamicDNS.Service.
6.Request
/gnudip/cgi-bin/gdipupdt.cgi
InternetGatewayDevice.Services.X_000E50_DynamicDNS.Service.
6.ServerPort
80
InternetGatewayDevice.Services.X_000E50_DynamicDNS.Service.
6.UpdateInterval
86000
InternetGatewayDevice.Services.X_000E50_DynamicDNS.Service.
6.RetryInterval
3
