TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 10 08/09/25 Thomson Technology
19
NOTE:
The following test menu is provided in TSC 800 Software
version 2.0 (or higher).
The ATS Mode sub-menus are organized as follows:
ATS Mode Menu No
Yes Auto (Automatic Operation & Programmed Test Mode)
Offload Test Continuous Test
Onload Test
Off (Controller Disabled) Timed Test: Selectable
15 - 240 Min.
Automatic Return to “Auto Mode”
LCD DISPLAY
ATS Mode Menu
No
Displays two messages that may be toggled between YES or NO by pressing the
INCREMENT or DECREMENT pushbuttons. Their functions are described as follows:
No Status message only, a change is required to gain access.
Yes The required variable to be entered to gain access and proceed. If the
password protect feature is enabled a prompt will appear requiring a
level 2 or greater security code be entered to allow a read-write access.
Entering a level 1 password will only permit a read only access.
The following ATS Mode Menu options are provided:
Auto This is the Default Selection and is required to enable all automatic
features of the controller. In this mode the TSC 800 Controller will
automatically transfer the load to the appropriate source based on
availability (the Utility supply is considered the preferred source). The
TSC 800 will provide automatic timed testing if enabled in programming.
Manual testing is disabled when the Auto ATS mode is selected (NOTE:
