TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 10 08/09/25 Thomson Technology
54
7.5.8. LOAD ON UTILITY PROGRAMMABLE OUTPUT
NOTE:
The following Programmable output features are provided in
TSC 800 Software version 2.0 (or higher).
The TSC 800 transfer controller output on terminal TB3-2 may be programmed for
different control functions. The powered output is supplied from the Utility supply and
must be used accordingly. The following programmable functions are available:
NOTE: Only one function may be programmed.
LOAD ON UTILITY Output energizes when the utility transfer
power-switching device is closed.
UTILITY NORMAL Output energizes when the utility supply is
energized and is within nominal voltage and
frequency limits.
DELAYED TRANSFER Output will energize “X” seconds following a
Transfer to Utility logic signal. The time period
is programmable 0-30 seconds.
NOTE:
The delayed transfer output time
delay function will be bypassed
should the original connected
source loose voltage.
