TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 10 08/09/25 Thomson Technology
17
5. TSC 800 DISPLAY MENUS
The TSC 800 contains a Liquid Crystal Display (LCD) that is visible on the front faceplate. The LCD
has pre-programmed display menus which are automatically displayed in an auto-Scrolling mode or
they may be selected manually by pressing the ENTER or EXIT pushbuttons in succession until the
desired menu is displayed. The display menu types and order in which they are programmed are as
follows:
NOTE:
The following display menus are provided in TSC 800 Software
version 2.0 (or higher).
SYSTEM TIME
STATS MENU
ATS MODE MENU
PROGRAM MENU
SYSTEM STATUS TIMER COUNTDOWN
UTILITY SUPPLY MENU
GEN SUPPLY MENU
NOTE: ATS MODE MENU access may be inhibited. Refer to programming instruction
for further details.
