Page #33 background imageLoading...
Page #33 background image
TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 10 08/09/25 Thomson Technology
27
5.8. STATS MENU
The STATS menu displays the recorded data logging for the following events:
NOTE:
The following stats menu is provided in TSC 800 Software
version 2.0 (or higher).
o Total Number of Transfers
o Total Number of Transfers due to source failure
o Number of Hours Controller is energized
o Number of Hours Load is on Utility
o Number of Hours Load is on Generator
The TSC 800 data logging has the maximum number of events memory as follows:
o The limit for the Total Transfers and SRC Fail Transfers is 10,000.
o The limit for the Total Hours, Load On SRC1 Hours, and Load On SRC2 Hours
is 160,000 hours.
LCD DISPLAY
Total Transfers
20
Displays the recorded data
NOTE: Zeroing of the Statistic Records can be accessed by entering the Program Menu with
a master password number. Consult THOMSON TECHNOLOGY factory for master password
number if required.
