TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 10 08/09/25 Thomson Technology
69
7.6.4.2.5. With the correct voltage displayed, press the ENTER
pushbutton to accept the correction factor number. Record the
correction factor number on the TSC 800 programming sheet for future
reference if required.
7.6.4.2.6. Repeat the above procedures for all remaining phases of
the generator supply as required.
7.6.4.2.7.
NOTE:
Once the span calibration setting has been done,
do not readjust any zero calibration points as this
will cause incorrect voltage readings.
